Boathouse Smokers - Horizontal Reverse Flow 600 Smoker
$5,495 – $20,000
Our Horizontal Reverse Flow series smokers are fabricated from new 1/4 thick carbon steel. We do not fabricate from used materials. Mill test reports can be provided upon request.
Dimensions
Cook chamber: 24” depth x 60” length x 36" tall
Firebox: 24” x 24” x 24”. Wheelbase = 54” wide x 84” long. Height is 82” to top of exhaust stack. Stock weight is 1,322 lbs.
Base Price $5,495.00
Standard Issue:
01. Two cook chamber doors with ¾ solid rod custom hinges.
02. Two cook racks with 6" clear between racks. (59"x22.5")
03. Two thermometers with 4" shroud.
04. 14"x36" expanded metal Front shelf
05. Removable tuning plates
06. 1.5 ball valve grease drain.
07. Four heavy duty Solid rubber 10" casters (2 Ridgid & 2 swivel)
08. Dual 4"x4"x16" exhaust tube with damper.
09. 24"x24"x24" Double wall insulated firebox with 1/2 solid door with 6 position latch system.
10. Wood storage rack below cook chamber. (Caster-Wheeled models only)
11. four 1.500 lb. D-rings at hip roof.
12. Black high-heat finish.
Options & Extra's
01. Extra cook racks. (Max of 3 total) Grows height of cook chamber x 0'-7" for each additional rack added = $800 each.
02. X-L extends depth of cook chamber from 24" to 27" = $700.00
03. XX-L extends depth of cook chamber to 30" = $1,200.00
04. 27"X27" double wall Insulated Firebox with 1/2 Door = $800.000
05. 30"x30" double wall insulated Firebox with 1/2 door = + $1,200.00
06. 1/2 thick Griddle top above firebox with 1.5 " lip & Grease Drain. = + $500.00
07. Three Rack cook cabinet with damper & exhaust above firebox. 23"x23" = Plus $1,195.00
08. Four Rack cook cabinet with damper & exhaust above firebox 23"x23" = + $1,295
09. Three rack warning cabinet with damper & exhaust above firebox 25"x25" = + $1,495.00
10. Four rack warning cabinet with damper & exhaust above firebox 28"x28" = + $1,595.00
11. 3" Airflow control valves with threaded pipe nipple=+$125.00 each Max of 3
12. 1/2 solid rod Sausage hangers. $15.00 each. (Maximum 4)
12.a Stainless steel front rack. 14"x60" $250.00
13. 5-inch Tel Thru thermometer with 6” shrouds = $100.00 each (minimum of 2)
14. Salamander Hot Box = +750.00
15. Extra Heavy duty 1,500 D-Ring = $25 each
16. Offroad Package (Black Golf-Cart wheels with 20" tires) wagon tow. 3500 lb. axle hub & spindle assembly. = Plus $1,295.00
17. Single axle trailer with wood storage = + $2500.00
18.Santa Maria grill above firebox with 16" flywheel, chain drive, ratchet, paw, bearing with 1" bore= Plus $1,295.00
19. Feet and legs for bolted trailer installation. = + $250.00 (Temp wheels for transport and shipping +$75.00)
20. Exhaust for food truck or trailer mount that is Extended above roofline = +$600.
21. Custom Logo (Message for quote)
22. High Heat clear finish = +150.00
23. Exhaust Thermometers = + $50.00 each
- Manufacturer
- Boathouse Smokers
- Category
- Smokers
- Fuel type
- Wood
- Price
- $5,495 – $20,000
- Height
- 82 in
- Width
- 84 in
- Depth
- 54 in
- Weight
- 1322 lb
